Cub Cadet Yanmar Lx490

Lx490Lx Series
Ref.
Part Number Description Qty
1 CY-194990-22140 NUT W/WASHER 8 2
2 CY-194990-22140 NUT W/WASHER 8 1
3 CY-194990-22140 NUT W/WASHER 8 2
4 CY-194990-22140 NUT W/WASHER 8 2
5 CY-1A8250-62090 FENDER M ASSY, 1
6 CY-1A7510-62100 BAR, ASSIST 1
7 CY-1A8250-62210 BRACKET ASSY, LAMP 2
8 CY-1A8250-62390 COVER,CUP HOLDER 1
9 CY-1A8250-62410 CAP, TOOLBOX 1
10 CY-1A8250-62460 LOCK, TOOLBOX 1
11 CY-1A8250-62471 PLATE ASSY, PTO SW 1
12 CY-1A8250-62490 STAY ASSY, PTO SW 1
13 CY-194697- 62560 CAP, HOLE 3
14 CY-198220-62920 COLLAR, CUSHION 17
15 CY-1A8250-63470 GROMMET 17
16 CY-1A8250-63700 STAY ASSY, GRIP 1
17 CY-1A8250-63920 BRACKET ASSY, FENDER 1
18 CY-198094-85710 GROMMET 38 1
19 CY-22157-080000 WASHER 8 8
20 CY-22157-080000 WASHER 8 2
21 CY-22157-080000 WASHER 8 1
22 CY-22372-080000 SNAP PIN (JASO 8) 2
23 CY-22486-080600 PIN H8X 60 2
24 CY-26106-080202 BOLT M 8X 20 PLATED 1
25 CY-26106-080202 BOLT M 8X 20 PLATED 2
26 CY-26106-080202 BOLT M 8X 20 PLATED 2
27 CY-26106-080352 BOLT M 8X 35 PLATED 8
28 CY-26487-080203 BOLT 8X20,SQ.ROOT 1
29 CY-194697-28270 BOLT M8X35,COLLAR HD 9
30 CY-198255-83550 WASHER 8,BC,PLAIN 9
31 CY-1A8250-62380 TUBE, 7X12X15 4
32 CY-1A8250-63750 GUARD TUBE, 1
Copyright 2011 Cub Cadet Yanmar LLC
195
Fig 112. Fender
