Cub Cadet Yanmar Lx490

Lx490Lx Series
Copyright 2011 Cub Cadet Yanmar LLC
21
Fig 9. Crankshaft & Piston
Ref.
Part Number Description Qty
1 CY-129652-21010 CRANKSHAFT ASSY 1
2 CY-129100-01580 PIN, PARALLEL 1
4 CY-119803-21200 GEAR, CRANKSHAFT 1
5 CY-121850-21290 PIN 1
6 CY-129400 -28121 GEAR, BALANCER 1
7 CY-22512-070140 KEY, 7X14 1
9 CY-22512-070140 KEY, 7X14 1
10 CY-119852-21650 V-PULLEY, CRANKSHAFT 1
11 CY-129795-21661 WASHER 1
12 CY-121850-21680 BOLT, V-PULLEY 1
13 C Y-121111-215 01 BOLT, FLYWHEEL 6
14 CY-129635-21590 FLYWHEEL ASSY 1
16 CY-124550-21600 GEAR, RING 1
17 CY-129508-22080 PISTON W/RING 4
19 CY-129004-22500 RING SET, PISTON 4
23 CY-129202-22300 PIN, PISTON(D26,L70) 4
24 CY-22252-000260 CIRCLIP 26 8
25 CY-729402-23100 ROD ASSY, CONNECTING 4
28 CY-121550-23200 BOLT, CONNECTING ROD 8
29 CY-129150 -23601 METAL, CRANKPIN 4
31 CY-129100-23910 METAL, PISTON PIN 4
32 C Y-12 915 0 -2 3611 METAL.PIN US=0.25 4
34 CY-129508-22900 PISTON W/RING .25OS 4
36 CY-129004-22950 RING SET, PISTON .25 4
