Fig 11. Lub. Oil System
Ref.
Part Number Description Qty
1 CY-129418-32000 PUMP ASSY, LUB.OIL 1
14 CY-129150-32020 GASKET, PUMP 1
15 CY-26450-060252 BOLT, M6X25 4
16 CY-129468-34810 GUIDE, DIPSTICK 1
17 CY-129558-34820 DIPSTICK, LUB.OIL 1
18 CY-129150-35042 GASKET, PIPE 1
19 CY-129550-35090 PIPE ASSY, OIL INLET 1
24 CY-26106-080122 BOLT M 8X 12 PLATED 1
25 CY-26106-080352 BOLT M 8X 35 PLATED 2
26 CY-129508-33010 COOLER ASSY, LUB.OIL 1
27 CY-129508-33050 O-RING 1
28 CY-129417-33110 NUT, OIL COOLER 1
29 CY-129006-35100 BRACKET ASSY, FILTER 1
30 CY-119802-35110 BRACKET, FILTER 1
31 C Y-129417-35150 STUD, L=67 1
32 C Y-12 915 0 -35111 GASKET, BRACKET 1
34 CY-129648-44400 JOINT, PT1/4 1
35 CY-129645-49030 PIPE, COOLER INLET 1
36 CY-171008-03990 CLIP, HOSE 18.5 1
38 CY-23080-015000 CLAMP 1
39 CY-26106-080202 BOLT M 8X 20 PLATED 3
40 CY-129150-35153 FILTER 80X80L 1
