Cub Cadet Yanmar Lx490

Lx490Lx Series
Copyright 2011 Cub Cadet Yanmar LLC
35
Fig 16. Fuel Injection Valve
Ref.
Part Number Description Qty
1 CY-729530-53100 VALVE ASSY,INJECTION 4
2 CY-129937-53000 VALVE ASSY,INJECTION 4
5 CY-114250-53080 NUT, CASE 4
6 CY-129508-53100 HOLDER ASSY, NOZZLE 4
9 C Y-1142 5 0 -5 312 0 SPRING, NOZZLE 4
10 C Y-1142 5 0 -5 313 0 SEAT, SPRING 4
11 CY-114250-53140 PLATE, STOP 4
12 CY-114250-53210 PIN 8
13 CY-119803-53400 SHIM SET 4
40 CY-123907-11601 SEAL 4
41 CY-119305-59120 RETAINER 2
44 CY-129150-59131 BOLT M4X14,HEX.SCKT. 2
45 CY-129550-59120 RETAINER, PIPE 1
48 CY-129150-59131 BOLT M4X14,HEX.SCKT. 2
50 CY-129508-59910 PIPE ASSY, INJECTION 1
51 CY-129508-59920 PIPE ASSY, INJECTION 1
52 CY-129508-59930 PIPE ASSY, INJECTION 1
53 CY-129508-59940 PIPE ASSY, INJECTION 1
54 CY-123907-59540 BOLT, JOINT M6 5
55 CY-129508-59550 PIPE ASSY, RETURN 1
56 CY-123907-59550 PACKING 5
57 CY-123907-59560 JOINT 1
58 CY-129508-59570 PIPE ASSY, RETURN 1
59 CY-124722-59050 CLIP, HOSE 2
60 CY-129508-59510 PIPE, FUEL RETURN 1
61 CY-22190-080002 SEAL WASHER 8S 1
