Cub Cadet Yanmar Lx490

Lx490Lx Series
Copyright 2011 Cub Cadet Yanmar LLC
37
Fig 17. Starting Motor
Ref.
Part Number Description Qty
1 CY-129429-77011 STARTER ASSY 1
2 CY-X0283060061 ROLLER 5
3 CY-X9490561370 NUT 1
4 CY-X9491200240 BALL 1
5 CY-129429-77210 YOKE ASSY 1
6 CY-129429-77220 ARMATURE ASSY 1
7 CY-129429-77230 BEARING 1
8 CY-129129-77240 BEARING 1
10 CY-129429-77250 PINION ASSY 1
11 CY-129129-77260 RETAINER 1
13 CY-129129-77270 PINION 1
14 CY-129429-77270 FRAME 1
15 CY-129429-77280 HOLDER ASSY 1
16 CY-129429-77290 SPRING 4
18 CY-129429-77310 SCREW 2
19 CY-129429-77320 SCREW 2
20 CY-129429-77330 BOLT 2
21 CY-129129-77340 SPRING 1
22 CY-129429-77340 CAP 1
23 CY-129129-77350 O-RING 2
24 CY-129429-77350 GASKET 1
25 CY-129129-77362 COVER 1
26 CY-129429-77360 COVER 1
27 CY-129129 -77370 NUT 1
28 CY-129429-77370 PLUNGER 1
29 CY-129429-77380 STARTER KIT 1
30 CY-129429-77390 STARTER KIT 1
31 C Y-26116 -12 02 52 BOLT M12X 25 PLATED 2
