Cub Cadet Yanmar Lx490

Lx490Lx Series
Ref.
Part Number Description Qty
1 CY-1A8275-12310 TIE-ROD ASSY, L 1
2 CY-1A8275-12330 END ASSY, ROD L 1
3 CY-1A8275-12440 COVER, DUST 1
4 CY-1A8275-12450 RING, COVER 1
5 CY-1A8275-12460 GREASE NIPPLES 1
6 CY-1A8275-12510 END ASSY, RACK L 1
7 CY-1A8275-12580 COVER, DUST 1
8 CY-1A8275-12590 RING, COVER 1
9 CY-1A8275-12600 C L I P, 1
10 CY-1A8275-12610 NUT, M20 1
11 CY-1A8275-12320 TIE-ROD ASSY, R 1
12 CY-1A8275-12340 END ASSY, ROD R 1
13 CY-1A8275-12440 COVER, DUST 1
14 CY-1A8275-12450 RING, COVER 1
15 CY-1A8275-12460 GREASE NIPPLES 1
16 CY-1A8275-12520 END ASSY, RACK R 1
17 CY-1A8275-12580 COVER, DUST 1
18 CY-1A8275-12590 RING, COVER 1
19 CY-1A8275-12600 C L I P, 1
20 CY-1A8275-12610 NUT, M20 1
21 CY-1A8275-12470 NUT,CASTLE 2
22 CY-22417-400400 COTTER PIN 4.0X40 2
Copyright 2011 Cub Cadet Yanmar LLC
57
Fig 13. Tie Rod
