Cub Cadet Yanmar Lx490

Lx490Lx Series
Ref.
Part Number Description Qty
1 CY-1A7180-13300 SHAFT, PROPELLER 1
2 CY-1A7140-14610 COVER,SHAFT FRONT 1
3 CY-198241-14650 BOOT, RUBBER 1
4 CY-1A8275-14650 COVER, SHAFT 1
5 CY-194640-26130 COUPLING 3
6 CY-1A8275-28410 SHAFT, DRIVE 1
7 CY-1A8275-28420 RETAINER, BEARING 1
8 CY-1A8275-28430 COVER, SHAFT REAR 1
9 CY-1E9170-54811 BOLT,REAMER 8X25 2
10 CY-22217-080000 WASHER, 8 2
11 CY-22242-000300 CIRCLIP 30 2
12 CY-22242-000300 CIRCLIP 30 2
13 CY-22252-000550 CIRCLIP 55 1
14 CY-23000-060000 CLAMP 60 2
15 CY-24104-060064 BALL BEARING 1
16 CY-24321-000500 O-RING 1A G-50.0 1
17 CY-24321-000500 O-RING 1A G-50.0 2
18 CY-24321-000500 O-RING 1A G-50.0 1
19 CY-26106-080122 BOLT M 8X 12 PLATED 1
20 CY-26106-080122 BOLT M 8X 12 PLATED 2
Copyright 2011 Cub Cadet Yanmar LLC
61
Fig 16. Propeller Shaft
