Cub Cadet Yanmar Lx490

Lx490Lx Series
Ref.
Part Number Description Qty
1 CY-194066-13640 PLUG 20 1
2 CY-1A7180137101 HOUSING, FRONT GEAR 1
3 CY-1A8275-13720 HOUSING, FRONT GEAR 1
4 CY-198072-13760 SEAL QLF709521.5 2
5 CY-1A8275-13760 BOLT, 10X28 4
6 CY-1A8275-13770 GEARBOX, FRONT L 1
7 CY-1A8275-13780 GEARBOX, FRONT R 1
8 CY-1C7100-15100 CAP,SEALING 90 2
9 CY-1C6900 -23120 BOLT M14X10,DRAIN 2
10 CY-1C6900-23150 WASHER 2
11 CY-194151-36670 PLUG PT02 2
12 CY-22252-000850 CIRCLIP 85 2
13 CY-22252-000900 CIRCLIP 90 2
14 CY-22252-000950 CIRCLIP 95 2
15 CY-22312-100180 PARALLEL PIN 10X 18 2
16 CY-24101-060124 BALL BEARING 2
17 CY-24101-062094 BALL BEARING 2
18 CY-24311-000180 O-RING 1A P-18.0 1
19 CY-24321-001300 O-RING 1A G-130.0 2
20 CY-26106-100302 BOLT M10X 30 PLATED 16
21 CY-26450-080122 BOLT 8X 12 2
22 CY-26756-100002 LOCK NUT M10 PLATED 4
Copyright 2011 Cub Cadet Yanmar LLC
65
Fig 19. Front Gear Case
