Fig 20. Front Shaft 2
Ref.
Part Number Description Qty
1 CY-1A7180-13820 GEAR, 2ND SHAFT 15 2
2 CY-1A7180-13830 PINION, FAINAL 11 2
3 CY-1A7180-13870 SHAFT, FRONT 2ND 2
4 CY-1A7180-13880 BEARING, TM207UR 2
5 CY-24104-062104 BALL BEARING 2
Fig.20. FRONT SHAFT(2
0CNP5-G37900
0CNP5-G37900
20. FRONT SHAFT(2
(F)=
(E)=
(D)=
(C)=LX490
(B)=LX450
(A)=LX410
LEV.REF. PARTS NO. DESCRIPTION
RI
Q'TY
(F)(D)(C)(B)(A) (E)
GEAR, 2ND SHAFT 151A7180-1382011 222
PINION, FAINAL 111A7180-1383012 222
SHAFT, FRONT 2ND1A7180-1387013 222
BEARING, TM207UR1A7180-1388014 222
BALL BEARING24104-06210415 222
