Cub Cadet Yanmar Lx490 - Page 85

Lx490Lx Series
Ref.
Part Number Description Qty
1 CY-194990-22140 NUT W/WASHER 8 2
2 CY-1A8240-22500 TURNBUCKLE ASSY 1
3 CY-194300-22260 TURNBUCKLE M10 1
4 CY-194150-22480 NUT M10 1
5 CY-1A8240-22540 ROD, L.H. SCREW 1
6 CY-1A8240-22550 ROD ASSY, R SCREW 1
7 CY-26716-100002 NUT 10 1
8 CY-1A8240-22520 LINK, CLUTCH 1
9 CY-1C6281-52320 PIN 8,COME-OFF SNAP 2
10 CY-22137-080000 WASHER 8, POLISHED 1
11 CY-22157-080000 WASHER 8 1
Copyright 2011 Cub Cadet Yanmar LLC
85
Fig 35. Clutch Link
