30 se c t i O n 7— se r v i c e
Deck Removal
WARNING! The muffler at the rear of the tractor
may be extremely hot, and could cause serious
burns. Use extreme caution when near the muffler.
Allow the muffler to fully cool before removing the
Remove the mower deck from the tractor as follows:
Apply the parking brake. Remove ignition key and both
spark plug caps.
2.
replace the pin in front of pedal in the deck height bracket
to secure it in place.
NOTE: There is a certain amount of spring tension due to
the weight of the deck. When removing the lift linkage
from the deck the tension of the springs will go from the
deck to the deck lift pedal. Not capturing the deck lift pedal
while removing the lift linkage from the deck will cause it
to snap back.
lever toward the back of the tractor, then remove the belt
Remove the four hair pins from the right and left side of the 4.
5.
are able to remove the deck.
Turn the front caster wheels outward.6.
To install reverse the process.7.
Adjust the belt tension according to the instructions on 8.
Replacing the Deck Belt
Follow the instructions for removing the deck.
Unscrew the wing nuts from the deck covers and remove 2.
both covers.
Using a ⁄
drive end into the ⁄
7-4. While holding the idler arm back, loosen the deck belt
from the pulley and slide the belt away from the pulley.
Figure 7-2
Hair Pin
Hair Pin
Deck Lift
Bracket
Figure 7-3
Figure 7-4
