Controls & Features
4
12
Ignition
Switch
Module
Hour Meter/
Indicator Panel
PTO Switch
Index Plate
Deck Lift Pedal
Drive Pedal
Reverse Pedal
Throttle Control
Fuel Tank Cap
Seat Adjustment Lever
Parking Break
Engagement Lever
Choke Control
Figure 4-1
NOTE:
position on the tractor when facing forward while seated in the
Deck Lift Pedal
2
L
4
5
6
7
8
4
5
The deck lift pedal is located near the front of the tractor on the
left of the foot platform and is used to raise and lower the mower
position.
position, locking behind the notch on the front of the index
plate. Remove and replace the lock rod into the desired height
index hole, then push pedal forward and rock forward to unlock
and slowly allow the pedal to move back until it reaches the lock
rod.
Ignition Switch Module
WARNING! Never
leave a running
machine unattended.
Always disengage
brake, stop engine
and remove key to
prevent unintended
starting.
To start the engine, insert the key
into the ignition switch and turn
clockwise to the position.
Release the key into the position once
the engine has fired.
To stop the engine, turn the ignition key counterclockwise to the
CAUTION:
Module and operating the tractor in
.
