16 Section 5— operation
Engaging the PTO
Move the throttle control lever to the FAST position.
2.
Figure 5-1
NOTE: Always operate the tractor with the throttle lever in the
FAST position for the most efficient use of the cutting deck or
other (separately available) attachments.
Using the Deck Lift Pedal
Push the pedal forward until it locks into the transport position,
locking behind the notch on the front of the index plate. Remove
and replace the lock pin into the desired height index hole, then
press down on the lift pedal and slowly allow the pedal to move
back until it reaches the lock pin.
Starting the Engine
WARNING! This tractor is equipped with a safety
interlock system designed for the protection of the
operator. Do not operate the tractor if any part of
the interlock system is malfunctioning. Periodically
check the functions of the interlock system for
proper operation.
WARNING! For personal safety, the operator must
be sitting in the tractor seat when starting the
engine.
NOTE:
instructions and refer to the Assembly & Set-Up section for
gasoline fill-up instructions.
2. Engage the parking brake. Refer to Figure 5-2.
Engage the Parking Brake
PTO Down
Figure 5-2
position. Refer to Figure 5-2.
4. Pull the choke control upward into the full choke position
NOTE: If the engine is warmed up, it may not be necessary
to place the choke control in the choke position.
5.
and FAST positions.
6. Turn the ignition key clockwise to the START position.
After the engine starts, release the key. It will return to the
CAUTION:
position for longer than ten seconds at a time. Doing
starter.
7. After the engine starts, deactivate the choke control.
NOTE:
cause the engine to run poorly.
