351804-1 Rev. 100
COM5000-8 TECHNICAL MANUAL
34
351293-1 351293-1
351285-1
351280-1
L163209-1 351289-1
FRONT
TOP VIEW
Figure 5.4.1B. 1.25kW PA Module
1.25 kW
COMBINER
350W Amp #1A
350W Amp # 1B
PA
CONTROLLER
FAN
FAN
FAN INTERFACE
