351804-1 Rev. 100
COM5000-8 TECHNICAL MANUAL
GENERAL
This manual describes the 5 kW Linear Power Amplifier that is part of a 5 kW Transmitter. The 5 kW
Transmitter comprises the COM5000-8 power amplifier with the T-4180 Exciter as pictured above.
This manual provides a basic description of Transmitter operation. For detailed operation of the Exciter,
refer to the T-4180 manual.
CONFIGURATION
The 5-kW Transmitter (351800-1) comprises the following modules:
System Controller module 1638-1000-12
1.25 kW Power Amplifier module (Qty: 4 ea.) 351270-2
Power Supply module 351830-2
Output Combiner module L163145-1
T-4180 Exciter module 1644-1000-4
