Cubic COM5000-8 User Manual

351804-1 Rev. 100
COM5000-8 TECHNICAL MANUAL
52
5.5 SPARE MODULES AND ASSEMBLIES
Spare Modules:
Description
QTY
Per
COM5000-8
PART NUMBER
System Controller
1
1638-1000-12
1.25 kW Power Amplifier
4
351270-2
Power Supply
1
351830-2
Output Combiner
1
L163145-1
T-4180 Exciter
1
1644-1000-4
Spare Assemblies:
Description
QTY
Per
COM5000-8
PART NUMBER
Part of
PA/Driver heatsink assembly
4
351275-1
1.25kW PA Module
PA heatsink assembly
8
351280-1
1.25kW PA Module
PA/Combiner heatsink assembly
4
351285-1
1.25kW PA Module
Harmonic Filter assembly
4
L163184
1.25kW PA Module
PA Controller PCB
4
L163209-1
1.25kW PA Module
Fan Interface Plate assembly
4
351289-1
1.25kW PA Module
1.25kW PA module Fan
8
351293-1
1.25kW PA Module
ALC/Splitter PCB
1
1638-2001-2
System Controller Module
System Controller PCB
1
1638-2000-2
System Controller Module
Power Supply assembly
1
L162087
System Controller Module
System Controller module Fan
1
21000044
System Controller Module
Combiner module Fan
2
21000035
Combiner Module
AC Line Filter
1
C5915-00083
Rack Cabinet
