Cudy WR2100 User Manual

4
If your internet connection is through an Ethernet cable directly from the wall instead of
through NSL/Cable/Satellite modem, connect the Ethernet cable to the router’s WAN
port and skip steps 1, 2 and 3.
Connect your computer to the router (wired or wireless).
Wired: Turn off the Wi-Fi on your computer and connect it to router’s LAN port via an
ethernet cable.
Wireless: Connect your device to the router’s Wi-Fi using the SSID (network name) and
Password printed on the bottom of the router.
Launch a web browser and enter http://cudy.net/ or http://192.168.10.1/ in the
address bar. Use “admin” for password to log in.
Note: If the login windows does not appear, please refer to the FAQ.
Then the popup window will appear. Please follow step by step instructions to set up
the internet connections.
Note: If the popup windows does not appear, please click “Quick Setup” on the status
page.
You’re successfully connected co the internet!
Turn off the modem and remove
the battery if it has one.
Connect router’s internet port to
DSL/Cable Modem/Ethernet.
Turn on the modem and then wait about two
minutes for it to restart.
Connect the power
adapter to the router,
and wait a minute until
the systém LED changes
from flashing light to
solid light (either red or
blue), which means that
the system startup is
completed.
Internet
Power Socket
Modem

Cudy WR2100 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1733 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
VPN support	PPTP/L2TP/OpenVPN/WireGuard
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Number of guest networks (2.4 GHz)	1
Mobile network generation	-
Ethernet LAN (RJ-45) ports	4
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Product type	Tabletop router
Product color	White
LED indicators	Activity, Power
Antenna gain level (max)	5 dBi
Flash memory	16 MB
Internal memory	128 MB
Processor cores	2
Output current	1.5 A
Output voltage	12 V
Power source type	DC
Browser supported	Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0
Mac operating systems supported	MacOS
Windows operating systems supported	Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP
Cables included	LAN (RJ-45)
Package type	Box
Number of products included	1 pc(s)

Weight and Dimensions

Depth	137.5 mm
Width	204.8 mm
Height	38.5 mm
