Cudy WR2100 User Manual

5
LED and Button
Name
Status
Indication
System
LED
Solid light
Red
Internet is not connected.
Blue
Internet is connected.
Flashing
light
Red
System is starting up.
Blue
WPS is in progress.
Red-Purple-Blue
Software is upgrading.
Off
Power adapter is not connected to the device.
Ethernet
LED
On
The corresponding ethernet port is connected.
Off
The corresponding ethernet port is not connected.
Button
WPS
Press and hold for one second to enable the WPS function.
Reset
Press and hold for six seconds to reset the router to its
factory default setting.
Cudy Technical Support
For technical support from Cudy, please visit http://www.cudy.com/support or write
your inquiry to support@cudy.com.

Cudy WR2100 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1733 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
VPN support	PPTP/L2TP/OpenVPN/WireGuard
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Number of guest networks (2.4 GHz)	1
Mobile network generation	-
Ethernet LAN (RJ-45) ports	4
Security algorithms	WEP, WPA, WPA-PSK, WPA2, WPA2-PSK
Product type	Tabletop router
Product color	White
LED indicators	Activity, Power
Antenna gain level (max)	5 dBi
Flash memory	16 MB
Internal memory	128 MB
Processor cores	2
Output current	1.5 A
Output voltage	12 V
Power source type	DC
Browser supported	Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0
Mac operating systems supported	MacOS
Windows operating systems supported	Windows 10, Windows 2000, Windows 7, Windows 8, Windows 8.1, Windows 98SE, Windows NT, Windows Vista, Windows XP
Cables included	LAN (RJ-45)
Package type	Box
Number of products included	1 pc(s)

Weight and Dimensions

Depth	137.5 mm
Width	204.8 mm
Height	38.5 mm
