Cuisinart CPG-700 - Page 11

STEP 6 - ATTACHING TOOL HOOKS
--------------------------------------
STEP 7 - SIDE SHELF ASSEMBLY
--------------------------------------
• Attach the three Tool Hooks (30) to the
Side Shelf (29).
• Attach the Side Shelf Bracket Left (32) and Side
Shelf Bracket Right (31) to the bottom of the Side
Shelf using Screws (A) Washers (B) and Lock
Washers (C) as shown in the image.
STEP 8 - PAPER TOWEL ROD
-----------------------------------------------------------------------------------
• Place the Paper Towel Rod (34) into
the Paper Towel Bracket (33) and
attach it to the bottom of the side
shelf using two Screws (G).
ASSEMBLY INSTRUCTIONS
11
G
x 2
A
B
x4
x4
C
x4
