Cumberland Smart-Flex FLX-4629 User Manual

20 PNEG-1186 Smart-Flex (FLX-4629) Operation Instructions
4. Smart-Flex Optional Equipment
Smart-Flex Extension Unit (FLX-4820)
A Smart-Flex extension unit is available to extend the user interface to a more favorable location for easier
access. The maximum distance the extension unit can be mounted away from the main Smart-Flex
control is 200'. In addition to the extension unit, an Alpha 6344, eight (8) conductor extension wire is
needed to connect the two (2) components together. The extension wire is available in either 50' length
(FLX-4821-50) or 200' length (FLX-4821-200). Install the Smart-Flex extension unit according to the
instructions that are supplied with it. (See Figure 4A.)
Figure 4A Smart-Flex Extension Unit
