JetScan
™
STOPPING CONDITIONS & RECOVERY
13
JetScan
™
12
STOPPING CONDITIONS & RECOVERY
When notes are removed from the bottom stacker, the display will show:
Raise the two red, plastic “T”
handles at the same time and
hook them onto the metal shaft.
Then either:
• Move jammed notes forward/
back by manually rotating
the large, black feed rollers.
(See Helpful Hint on Page 5.)
• Press Clear to slowly move
the feeder for
war
d
.
• Press Strap to slowly move
the feeder in r
everse.
Remove all jammed notes and
foreign material.
DISPLAY
Currency or possibly foreign
material is jammed in the
paper path and must be
removed.
Remove all notes from
the top hopper and
bottom stacker.
Remove the hopper
extension, as shown
in inset.
Remove the feeder plate,
as shown at right.
Remove feeder plate by lifting with fingers in the
two depressions.
➧
➧
Users should either:
• Face the note, replace it in the bottom stacker, and press the appropriate
denomination value key.
•
Correctly face the note, return it to the top hopper, and press Cont.
DISPLAY
JetScan has identified a note
that is incorrectly faced.
➧
Do not use tools or metal devices to remove jammed currency from
paper path.
Use of tools or metal devices could cause machine damage and void
existing warranty.
For proper removal of jammed currency, see step No. 2 on Page 13.
1
2
