Cuppon CSD 150 User Manual

24 25
• The manufacturer reserves the right to make any changes which deemed benecial
or necessary.
• Electrical safety of your product can only be ensured if only it is connected to an
earthing system accurately. The manufacturer cannot be held responsible if these
conditions are not complied with.
• Assembly of electronic parts should be performed only by authorized personnel.
Any maintenance or service should be performed by an expert authorized by the
manufacturer.
• The product you purchased can be used as a general entrance and exit. It cannot
be used as an emergency exit.
• Do not put any foreign object into the rail region or door mechanisms.
• Please don’t prevent opening or closing of moving door or any equipment by any
object, equipment, or machinery.
• Do not force the door for opening or closing for any reason.
• Do not put inammable or burning objects next to the door.
• Do not reset functions of faulty door without assistance of an expert authorized
by the manufacturer company, or without reading assembly and installation
instructions.
• Please do not perform works which should normally be performed by the expert
authorized by the manufacturer.
• Please do not put moving tools or materials within radar detection distance of the
door. It is recommended to use micro-radar with curtain photocell for a full safety.
• While the door is in automatic state, do not clean, and make sure that electronic
parts don’t have contact with water.
• During maintenance of door, please make sure that the system is closed.
• Please do not exert excessive power to the doors or accessories under any
condition.
• Please keep DVDs for future reference which include assembly and user’s manual,
and assembly video of the product.
• Please cut off the power prior to perform any work on the system.
• Check if the earthing is done properly. All metal components of closing sections
(building doors, garden gates, etc.) and all components of the system which have
earthing end to the earthing line.
SAFETY WARNINGS
Operating Voltage 230 V AC±10% 50 Hz
Motor Voltage 24 V DC
Opening Speed (Adjustable) 0.9m/s
Closing Speed (Adjustable) 0.7m/s
Max. Leaf Weight 75kg (1 leaf), 75+75kg (2 leaves)
Kit Measurements & Weight 50x30x15cm/11kg
Fault Notication With a led indicator on the main board
Motor Lock Available
Self Positioning Available
Extra Photocell Optional
Manual Sensor Optional
Numbering Machine & RF Card Reader Optional
Always Closed-Open Available
Automatic Operation Available
Current Taken 0.6A
Motor Power 95W
Opening Time 3 & 5 seconds (2 levels with a switch)
Protection Degree IP 20 (Only for dry environments)
Operating Temperatures from -15°C to 60°C
Aluminum Frame Measurements 3.5 / 4.5 / 6.5 meters
Adjustable Open Time 2 levels with a switch
Adjustable Speed Available
Photocell Available
Height Photocell Optional
Curtain Photocell Microwave Radar Optional
Bluetooth Technology Optional
Elbow Button Optional
ID Car Pass Optional
Only Entrance-Exit Available
Half-Opening Manually adjustable
TECHNICAL SPECIFICATIONS
Technical Specications
CSD 150
AUTOMATIC SLIDING

Cuppon CSD 150 Specifications

General

Brand	Cuppon
Model	CSD 150
Category	Door Opening System
Language	English
