PARTS
The parts and the equipment constituting the product
have been shown in the below.
07 Belt
08 Belt Coupling Piece (2)
09 Double Carrier Roller (4)
10 Stopper (2)
11 Side covers (Right-Left)
12 Idle Roller
NO DESCRIPTION NO DESCRIPTION
01 Microprocessor Control Unit
02 Radar Movement Sensor (2)
03 Safety Photocell
(Receiver-Transmitter)
04 Position Switch
05 Motor with Encoder
06 Curtain Radar (Option)
01
02
03
04
05
06
07
08
09
10
11
12
SOCKET CONNECTIONS
WARNING: Materials used during assembly should be in
accordance with applicable standards, and connections
should be performed by an authorized personnel.
PHOTOCELL
TRANSMITTER
CLOSE OPEN
CSD 150
AUTOMATIC SLIDING
