13
Removing the Oven Door
The oven door can easily be removed as follows:
1. Open the door completely.
2. The swivel retainers of the right hand and left hand hinges
are hooked onto the metal bar above them. Lift the retainers
as shown.
3. Close the oven door gently until it meets the open retainer.
4. Support the door by holding both sides at the same time. Continue
to close the door further then lift to disengage the hinge from the
bottom.
5. Pull the oven door towards you to remove the hinges from
their slots.
6. To replace the door, repeat the above steps in reverse order ensuring
the hinge slot engages over the edge of the door frame.
* All images are for indication only; please refer to your individual unit for actual item.
