CUSHCRAFT R6000 - Page 7

27 204727 UPPER PLASTIC 2
CLAMP
28 204728 LOWER PLASTIC 2
CLAMP
29 204729 ALU CLAMP 1
ASSEMBLY
53 050053 PLASTIC 1/2” 1
CAP (1.3 cm)
64 014764 SS MACHINE #8-32 x 2-1/4” 10
SCREW (5.7 cm)
77 050077 PLASTIC 3/8” 3
CAP (1.0 cm)
87 014387 SS LOCK #8-32 12
NUT
407 030407 SS WORM 5/8” 9
CLAMP (1.6 cm)
409 030409 SS WORM 15/16” 1
CLAMP (2.4 cm)
411 030411 SS WORM 1-1/4" 4
CLAMP (3.2)
412 030412 SS WORM 1-1/2" 2
CLAMP (3.8 cm)
813 204813 PLASTIC 2
CLAMP
814 204814 ALU CLAMP 1
ASSEMBLY
923 204923 PLASTIC 2
CLAMP
BA BASE 1
ASSEMBLY
BB ALUMINUM 1-1/4" x 48” 1
TUBE (3.2 x 121.9 cm)
BC ALUMINUM 1-1/8" x 48" 1
TUBE (2.8 x 122 cm)
BD ALUMINUM 1” x 48” 1
TUBE (2.5 x 122)
BE ALUMINUM 1" x 10" 1
TUBE (2.5 x 25.4 cm)
BF ALUMINUM 1/2” x 21” 1
TUBE (1.3 x 53.3 cm)
BG ALUMINUM 1/2" x 48" 3
TUBE (1.3 x 122)
BH ALUMINUM 1/2” x 48” 2
TUBE (1.3 x 122 cm)
BJ ALUMINUM 1/2” x 36” 1
TUBE (1.3 x 122)
BK ALUMINUM 3/8” x 18” 2
TUBE (1.0 x 45.7)
BL ALUMINUM 3/8” x 6” 3
TUBE (1.0 x 15.2)
BM ALUMINUM 3/8” x 12” 1
TUBE (1.0 x 30.5 cm)
CS1 12 METER 1
TRAP
CS2 17 METER 1
TRAP
6
KEY P/N DISPLAY DESC SIZE
412
813
FIGURE
F2
FIGURE
F3
R6000
BH
BH
77
27
407
BC
BB
BG
87
87
64
64
87
64
87
64
BG
BM
407
407
BG
BG
87
BG
814
87
64
BA
64
29
BB
413
CS2
CS1
1/2” (1.3 cm)
Below Bracket
