LIMITED WARRANTY
Cushcraft Corporation, P.O. Box 4680, Manchester, New Hampshire 03108, warrants to the original purchaser for one year
from date of purchase that each Cushcraft antenna is free of defects in material or workmanship. If, in the judgement of
Cushcraft, any such antenna is defective, then Cushcraft Corporation will, at its option, repair or replace the antenna at
its expense within thirty days of the date the antenna is returned (at purchasers expense) to Cushcraft or one of its
authorized representatives. This warranty is in lieu of all other expressed warranties, any implied warranty is limited in
duration to one year. Cushcraft Corporation shall not be liable for any incidental or consequential damages which may
result from a defect. Some states do not allow limitations on how long an implied warranty lasts or exclusions or limitations
of incidental or consequential damages, so the above limitation and exclusion may not apply to you. This warranty gives
you specific legal rights, and you may also have other rights which vary from state to state. This warranty does not extend
to any products which have been subject the misuse, neglect, accident or improper installation. Any repairs or alterations
outside of the Cushcraft factory will nullify this warranty.
48 PERIMETER ROAD, MANCHESTER, NH 03108 USA
TELEPHONE: 603-627-7877 • FAX: 603-627-1764 • E-mail: techsup@cushcraft.com
SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE
COMMUNICATIONS ANTENNAS
Frequency, meters 10,12,15,17,20,30,40,80
Gain, dBi 3
Wavelength each band Half-wave
VSWR 1.2:1 typical
2:1 bandwidth, KHz 10m (1700)
12m (100)
15m (450)
17m (100)
20m (250)
30m (100)
40m (100)
80m (70)
Power Rating, Watts 1500
Radiation angle, deg. 16
Horizontal rad, deg. 360
Height, ft(m) 34.5 (10.5)
Mast size range, in 1-3/4 to 2-1/8
(cm) (4.4-5.4)
Wind load, ft
2
(m
2
) 2.5 (.23) antenna
1.5 (.13) guy ropes
Weight, lb. (kg) 24 (10.8)
SPECIFICATIONS
