CHECKING AND REPLACING
FUSE (AF)
1. Park the vehicle on level ground
and apply the parking brake rmly.
2. Stop the engine, open the hood
and support the hood.
(1) Fuse Box
3. Open the fuse box cover. There
are spare fuses and fuse tongs in
the center of the box.
(1) Fuse Tong
4. Check or replace the fuse with the
fuse tongs.
5. If fuses are blown repeatedly, con-
tact your Dealer.
UUVO756A
UUVO757A
U12O774A
MAIN FUSE (SLOW-BLOW FUSE) (AG)
(1) Slow-blow Fuse
If the start motor and all electrical de-
vices do not operate at all when turn-
ing the key the switch to the "START"
position, the first thing to inspect is
the main fuse.
1. Remove the engine inspection
shield.
2. Check if the yellow slow blow fuse
installed to the positive start motor
cable is blown.
3. Remove the tape and replace the
fuse with a new one if necessary.
UUVO758A
