Block diagram, wiring
D. Instantaneous current and to improve power ratio, it should be fitted the A.C.L. to
R.S.T. input side under the following circumstance:
a. Where power supply capacity is larger than 500 KVA.
b. Using thyrister, phase advance capacitor etc. from the same power supply.
A.C.L. Specifications table:
Voltage (V) Model Current (Ar.m.s) Induction Value
CT-2002-A75 6A 1.8mH
CT-2002-1A5 10A 1.1mH
CT-2002-2A2 15A 0.71mH
CT-2002-3A7 20A 0.53mH
CT-2002-5A5 30A 0.35mH
CT-2002-7A5 40A 0.26mH
220
380
|
440
CT-2002-011 60A 0.18mH
CT-2002-015 80A 0.13mH
CT-2002-022 120A 0.09mH
CT-2002-030 150A 70uH
CT-2002-037 200A 50uH
CT-2002-045 250A 44uH
CT-2002-055 300A 35uH
CT-2002-075 400A 27uH
CT-2002-093 500A 21uH
CT-2004-A75 5A 4.2mH
CT-2004-1A5 5A 4.2mH
CT-2004-2A2 7.5A 3.6mH
CT-2004-3A7 10A 2.2mH
CT-2004-5A5 15A 1.42mH
CT-2004-7A5 20A 1.0mH
CT-2004-011 30A 0.7mH
CT-2004-015 40A 0.53mH
CT-2004-022 60A 0.36mH
CT-2004-030 80A 0.26mH
CT-2004-037 100A 0.21mH
CT-2004-045 120A 0.18mH
CT-2004-055 150A 0.14mH
CT-2004-075 200A 0.11mH
CT-2004-093 250A 0.10mH
CT-2004-112 300 70uH
Notes: The A.C.L. for 220V and 380V/460V have different induction values, please does
not mix up.
