CUTES CT-2000F Series User Manual

C.TY TNHH TỰ ĐỘNG HÓA VIỆT TRUNG 02413.281.181-0989.984.666
Website:www.viet-trung.com.vn Đ/c:194-Nguyễn Trãi-Võ Cường-TP.Bắc Ninh
9
Block diagram, wiring
C. Connecting the power supply and the AC motor
Connect the main circuit, by wiring according to the main circuit terminal connection
diagram. Care is required not to make a mistake when connecting the input and
output terminals, lest it will cause inverter damage. Specifications of main circuit
path and NFB are as follow:
Voltage (V)
Model NFB (A) Wire size for
circuit (mm
2
)
CT-2002-A75 6A 2~5.5
CT-2002-1A5 10A 2~5.5
CT-2002-2A2 15A 3.5~5.5
CT-2002-3A7 20A 5.5
CT-2002-5A5 30A 5.5~8
CT-2002-7A5 40A 5.5~8
220
380
|
440
CT-2002-011 60A 22
CT-2002-015 80A 30
CT-2002-022 120A 38
CT-2002-030 150A 38~100
CT-2002-037 200A 38~100
CT-2002-045 250A 60~100
CT-2002-055 300A 100
CT-2002-075 400A 100~200
CT-2002-093 500A 100~200
CT-2004-A75 5A 2~5.5
CT-2004-1A5 5A 2~5.5
CT-2004-2A2 7.5A 2~5.5
CT-2004-3A7 10A 3.5~5.5
CT-2004-5A5 15A 3.5~5.5
CT-2004-7A5 20A 5.5
CT-2004-011 30A 8~14
CT-2004-015 40A 8~14
CT-2004-022 60A 22
CT-2004-030 80A 22
CT-2004-037 100A 30
CT-2004-045 120A 50
CT-2004-055 150A 38~100
CT-2004-075 200A 38~100
CT-2004-093 250A 60~100
CT-2004-112 300A 100
