Cutting Edge 100A MPPT User Manual

Rev 20200515 Page 3
Innovative Renewable Energy Solutions
SPECIFICATIONS:
BATTERY VOLTAGE 12V OR 24V
MAXIMUM CHARGE CURRENT 100A
MAXIMUM SOLAR INPUT
23V VOC FOR CHARGING 12V BATTERY/BATTERIES
46V VOC FOR CHARGING 24V BATTERIES
12V BATTERY/BATTERIES 24V BATTERIES
EQUALIZATION 14.4V 28.8V
FLOAT CHARGE 13.7V DEFAULT, ADJUSTABLE 27.4V DEFAULT, ADJUSTABLE
DISCHARGE CUT OFF 10.7V DEFAULT, ADJUSTABLE 21.4V DEFAULT, ADJUSTABLE
DISCHARGE RECONNECT 12.6V DEFAULT, ADJUSTABLE 25.2V DEFAULT, ADJUSTABLE
LOAD “ON”, AKA NIGHT MODE 8V SOLAR INPUT 16V SOLAR INPUT
LOAD “OFF”, AKA DAY MODE 8V SOLAR INPUT 16V SOLAR INPUT
USB OUTPUT 5V / 2.5A MAX
POWER CONSUMPTION <10mA
OPERATING TEMPERATURE WITH-
OUT FORCED CONVECTION
50°C
SIZE 6-7/16” L X 3-3/4” W X 1-11/16” H
