CVS 7970 - Adjustment 2 to 15 PSI, Assembly

7
Figure 8 – CVS Series 7970 Low Pressure Pilot – Adjustment 2 to 15 PSI, Assembly
CVS Series 7970 Low Pressure Pilot – Adjustment 2 to 15 PSI, Parts List
Item Number Part Number
Description Qty.
1 CVS 7910A Adjusting Cap, Black Delrin 1
2 CVS 7920A 6/16" Ball Bearing, SST 1
3 CVS 7911A Spring Guide, Black Delrin 1
4 CVS 7970A Spring, 302 Stainless Steel 1
5 CVS 79712A Lock Nut, Black Delrin 2
6 CVS 79709A Spring Housing, 316 SST 1
7 CVS 79708A Stop Plate, 316 SST 1
8 CVS 79704A Body Housing, 316 SST 1
9 CVS 79707A Upper Stem, 316 SST 1
10 CVS 79706A Lower Stem, 316 SST 1
11 CVS 79730 Adapter, Low Pressure, 316 SST 1
12 CVS 79701LP Piston Housing, 316 SST 1
13 V-75-145 o-ring, Viton Coated TFE 2
14 CVS 79702LP Piston, LP, 316 SST 1
15 CVS 79731 Wiper Ring, Viton 1
16 V-75-010 Seal, Viton Coated TFE 2
17 V-75-008 Seal, Viton Coated TFE 2
