Safety Symbols
The WARNING sign denotes a hazard. It calls attention to a procedure, practice or the like which,
if not correctly performed or adhered to, could result in injury or loss of life. Do not proceed beyond
a WARNING sign until the indicated conditions are fully understood and met.
The CAUTION sign denotes a hazard. It calls attention to an operating procedure, practice, or the like,
which, if not correctly performed or adhered to could result in damage to or destruction of part or all of
the equipment. Do not proceed beyond a CAUTION sign until the indicated conditions are fully understood
and met.
Grounding Requirements
The synthesizer is equipped with a three-conductor power cord which, when plugged into an appropriate
receptacle grounds the instrument. The offset pin on the power cord three-prong connector is the ground wire.
Rack Installation
This instrument can be rack mounted by using a rack mounting kit.
Rack Mounting kit; 2 brackets that are attached to the sides of the instrument by 4 M5 screws.
Installation of Instrument Stand (optional)
An instrument stand can be attached to the unit using the instrument stand kit.
Instrument stand kit: 2 stands (right, left) that are attached to the sides of the instrument by 4 M5 screws
(same screws as for rack installation).
Repackaging for Shipment
The following is a general guide for repackaging for shipment.
NOTE: If the instrument is to be shipped to Cwejman Sound for service or repair, attach a tag to the
instrument identifying the owner and indicating the service or repair to be carried out, include the serial
number. Place the instrument in its original container if available. If the original container is not available
wrap the instrument in heavy paper or plastic before placing in an inner container. Use plenty of packing
material around all sides of the instrument and protect panel faces with cardboard strips.
Place the instrument and inner container in a heavy carton or wooden box and seal with strong tape or
metal bands. Mark the shipping container DELICATE INSTRUMENT or FRAGILE.
Warm up time
After start up the unit requires 5 to 10 minutes to allow circuits to stabilise.
Specification
The following is an account of the entire unit and the technical performance of each individual module.
In addition there is a more detailed description of the characteristics of the unit's functions including
descriptions of the modules, measurements of waveforms, spectrum analysis, frequency response, etc.
3
WEIGHT
5 kg
DIMENSIONS
440mm (L), 215mm (H), 70mm (D)
POWER
115/230Vac ± 10%, 20VA
