CyberPower Ecologic Series User Manual

TROUBLESHOOTING
Problem Possible Cause Solution
Circuit breaker button is projecting
from the side of the unit.
Circuit breaker has been tripped
due to an overload.
Turn the UPS o and unplug at
least one piece of equipment.
Wait 10 seconds, reset the circuit
breaker by pressing the button,
and then turn the UPS on.
The UPS does not perform
expected runtime.
Battery not fully charged.
Recharge the battery by leaving
the UPS plugged in.
Battery is worn out.
Contact CyberPower Systems
about replacement batteries
The UPS will not turn on.
The on/o switch is designed
to prevent damage from rapidly
turning it o and on.
Turn the UPS o. Wait 10 seconds
and then turn the UPS on.
The unit is not connected to an
AC outlet.
The unit must be connected to a
110/120V 50/60Hz outlet.
The battery is worn out.
Contact CyberPower Systems
about replacement batteries
Mechanical problem. Contact CyberPower Systems
The frequency is outside of the
operating range of 47-63Hz.
Turn the UPS o. Make sure the
frequency range is within 47-63Hz.
Or you can turn the UPS on in
battery mode.
PowerPanel® Personal is inactive
(all icons are gray).
The USB cable is not connected.
Connect the USB cable to the UPS
unit and an open USB port on the
back of the computer.
The USB cable is connected to a
bad USB port.
Check for a dierent USB port and
plug the cable in.
The unit is not providing battery
power.
Shutdown your computer and turn
the UPS o. Wait 10 seconds and
turn the UPS back on. This should
reset the unit.
Additional troubleshooting and contact information can be found online at CyberPowerSystems.com/support
TECHNICAL SPECIFICATIONS
SYSTEM FUNCTION BLOCK DIAGRAM
Model EC450G EC550G EC750G EC650LCD EC850LCD
Capacity
450VA / 260W 550VA / 330W 750VA / 450W 650VA / 390W 850VA / 510W
Nominal Input
Voltage
120 VAC
Input Frequency
47 Hz to 63 Hz
On-Battery
Output Voltage
120Vac ± 5%
On-Battery
Output Frequency
50Hz/60Hz ± 1% (auto-sensing)
Max Load for
UPS Outlets
450VA / 260W 550VA / 330W 750VA / 450W 650VA / 390W 850VA / 510W
Max Load for
Full-time Surge
Protection Outlets
10 Amps
On-Battery
Output Wave Form
Simulated Sine Wave
Operating
Temperature
32°F to 104° F / 0° C to 40° C
Operating
Relative Humidity
0 to 90% non-condensing
Size
W x H x D
5.9 x 3.1 x 10.6 in.
150 x 79 x 269 mm
5.9 x 3.1 x 10.6 in.
150 x 79 x 269 mm
7 x 3.1 x 12.2 in.
178 x 79 x 310 mm
5.9 x 3.1 x 10.6 in.
150 x 79 x 269 mm
7 x 3.1 x 12.2 in.
178 x 79 x 310 mm
Net Weight
4.5 lbs / 2.1 kg 6.0 lbs / 2.7 kg 7.7 lbs / 3.5 kg 6.4 lbs / 2.9 kg 7.7 lbs / 3.5 kg
Typical Battery
Recharge Time
8 hours typical from total discharge
Typical Battery
Life
3 to 6 years, depending on number of discharge/recharge cycles
Battery
Sealed Maintenance Free Lead Acid Battery
Safety Approvals
UL1778(UPS), cUL CSA C22.2 No.107.3-05, FCC/DoC Class B
Input Output
Battery Mode
Normal Mode
EMI
Filter
Surge
Suppressor
Inverter
Charger
AC / DC
Battery

CyberPower Ecologic Series Specifications
