CyberPower INTELLIGENT UPS Series User Manual

TECHNICAL SPECIFICATIONS
Model CP850AVRLCDa CP1000AVRLCDa CP1350AVRLCDa CP1500AVRLCDa
Capacity 850VA / 510W 1000VA / 600W 1350VA / 815W 1500VA / 900W
Nominal Input Voltage 120Vac
Input Frequency 60 Hz ± 3 Hz
On-Battery Output Voltage 120Vac ± 5%
Max. Load for UPS Outlets
(5 Outlets)
850VA / 510W 1000VA / 600W 1350VA / 815W 1500VA / 900W
Max. Load for Full-Time
Surge Protection outlets
12 Amps
(9 outlets)
12 Amps
(10 outlets)
12 Amps
(12 outlets)
On-Battery Output Wave
Form
Simulated Sine Wave Form
Operating Temperature + 32°F to 104° F / 0° C to 40° C
Operating Relative Humidity 0 to 90% NON-CONDENSING
Size (W x H x D) 3.9” x 9.0” x 10.2” (100*227.5*260mm)
3.9” x 9.8” x 13.7”
(99 x 249 x 348
mm)
3.9” x 11” x 14”
(100 x 280 x 355
mm)
Net Weight 15.0lbs / 6.8kg 22.2lbs / 10.1kg 25lbs / 11.3kg
Battery Type CyberPower / RB1290
CyberPower /
RB1290X2
CyberPower /
RB1290X2
Typical Battery Recharge
Time
8 hours
Typical Battery Life 3 to 6 years, depending on number of discharge/recharge cycles
Recommended Battery Sealed Maintenance Free Lead Acid Battery
Safety Approvals UL1778(UPS), cUL107., FCC/DoC Class B
SYSTEM FUNCTION BLOCK DIAGRAM
EMI
Filter
Surge
Suppressor
AVR
Charger
AC/DC
Battery
Inverter
Input Output
Normal Mode
Battery Mode
