CyberPower PDU31 Series User Manual

16
Web Interface
Intelligent PDU User Guide
Log Tab > Graphing
Item
Definition
HOST/GUEST#
Select the role of PDU (HOST or GUEST#) if PDUs are daisy
chained. Up to 3 GUEST PDUs can connect to 1 HOST PDU.
Graph Period
The time period is used to create a retroactive graph of the status
records. A large time period will require more time to render the
graph.
Graph Data
The data used to create a graph of the status records. Up to five
data points can be selected. A large number of data selected will
require more time to render the graph.
Graph Node
Select the Display All Nodes in Detail option to display the
selected data points along the graph. When the cursor is moved to
an individual data point, information about that point will be shown.
If this option is not selected, the graph will show only the line
(without the points), so less time is needed to render.
Draw
A graph of the status records will be created.
Reset
Reset the Graph Period to default (1 day).
Launch Graph in New
Window
A detailed view of the graph opens in a new browser window.
