5. Install the coax cable to the mounting plate on the front of the unit using a 14 mm open end wrench.
6. Plug the Ethernet or HDMI cable into the coupler on the front of the unit.
Visually inspect unit
1. Remove any packing material from unit.
2. Examine the unit to ensure that the assembly is correct and complete.
Assembly Procedure 771AT/772AT
Two people will be required for this procedure.
Read and understand all instructions thoroughly before assembling this unit. Check all items
carefully. If there is damage, see the Customer Service section of this manual for proper procedure
to return, replace, or reorder parts.
The words "left" and "right" denote the user's orientation.
Verify you have received the correct package
1. Read box label to verify the model number and voltage (optional) match what was ordered.
2. Verify paint color matches what was ordered.
Verify parts list shown below
DescriptionPart NumberQuantityItem
Base assemblyVaries11
Console assemblyVaries12
Foot pad12090-32223
Handle, RightNA14
Handle, LeftNA15
Base, Accessory tray770A-31616
Cover, Top, Accessory tray770A-31717
Cover, Bottom, Accessory tray770A-31818
Cover, Rear, Top, Right770A-32219
Cover, Rear, Outer, Right770A-323110
Cover, Rear, Inner, Right770A-324111
Cover, Rear, Top, Left770A-319112
Cover, Rear, Inner, Left770A-321113
Cover, Rear, Outer, Left770A-320114
Hardware packNA115
Owner’s Manual5771-X116
Assembly poster771AT-316117
Commercial Arc warranty sheet770A-415118
Page 27 of 95
Cybex 771A/771AT, 772A/772AT Arc Trainer Part Number 5771-4 K
