Service
Page 4-4
Error Codes
Error codes notify you of a problem condition and are displayed on the center of the console. These
codes can also help to indicate the part of the unit most likely to be causing the problem. Errors that
present a hazard to the user provide a measure of safety by causing a one second beep, stopping the
unit and locking out operation of the unit.
A log of errors can be viewed and cleared. Up to 10 errors can be stored.
To enter Test Mode: Press and hold down any key on the display while turning the power switch to
the on (I) position.
To view the Error Log: Press the Strides Per Minute key to display and cycle through error log; Press
again to cycle to the next stored error.
To clear the Error Log: Press the Scan key twice.
To exit Test Mode: Press the Stop key.
NOTE: A processor upset can cause a bAd#. See F then G.
Error Description
bAd0 Bad check sum. See F then E.
bAd2 Internal RAM error. See F then E.
bAd3 Watchdog timeout. See F then E.
Err3 Speed sense lost. See A and B.
Err5 No index switch sense within timed limits. This is declared when the timed elevation
reaches 0% without tripping the index. See D and A.
Err7 EEPROM error (memory lost, loads new defaults, enters Test Mode). See E.
ErrE Index switch always on (or switch disconnected or wired backwards). This means that timed
elevation has gone up 3 positions and the index is still sensed. See D.
Action
A Check the lower board
B Check the brake
C Check the speed sensor and speed sensor disc
D Check the elevation motor
E Replace the display board is problem persists
F Turn the power switch to the off (O) position and back on (I)
