CYBEX VR1 User Manual

1 4 08014 PULLEY ASSEMBLY, 4.50 IN.
2 4 08229 PIN,DETENT
3 4 11040-440 KNOB
4 1 11070-332 COUNTERWEIGHT
5 2 11090-374 END CAP
6 2 11090-376 RING, HANDLE GRIP
7 1 11100-400 ROTATION DECAL
8 1 12050-377 DECAL, START RLD
9 1 12060-317 SUPPORT TUBE
10 1 12060-336 P DETENT PLATE
11 1 12060-346 PIVOT PIN
12 1 12060-356 DECAL, LEG BAR ADJUST
13 2 12100-303 BUMPER
14 2 12210-347 GUIDE ROD CAP
15 2 12210-348 GUIDE ROD CAP
16 2 13000-322 ROLLER
17 2 13000-326 WT ROD .625 DIA X 51.51
18 1 13000-342 MOLDED TOP CAP
19 6 13000-353 FOOT PAD
20 1 13000-354 FOOT PAD
21 1 13000-355 FOOT PAD
22 2 13000-364 BEARING, FLANGE .62 ID. x .92
OD. x 1.75 LG
23 1 13000-400 HOLDER, WATER BOTTLE
24 1 13000-403 MOUNT, WATER BOTTLE HOLDER
25 1 13050-207 CUSHION TUBE
26 1 13050-300 END CAP, BEARING HOUSING
27 1 13060-002 CABLE ASSEMBLY
28 1 13060-200 VR1 MAIN FRAME
29 1 13060-203 CUSHION PIVOT
30 1 13060-205 CUSHION ARM
31 1 13060-318 SHAFT, PIVOT
32 1 13060-321 PLATE, PIVOT
33 1 13060-327 PIN, PIVOT
34 1 13061-202 CAM, LEG POSITIONING
35 1 13061-204 POSITIONING LEG PIVOT
36 1 13061-205 COUNTER WEIGHT
37 1 3900-438 DECAL, CYBEX
38 1 4505-331 BUMPER, 1.50 DIA
39 1 4605-511 INSERT,PLASTIC 5.94
40 1 4700C073 TOP WT 10-3 x 12
41 2 4715-336 WASHER
42 1 51198 WARRANTY BOOK (NOT SHOWN)
43 1 BH030207 PIN, WEIGHT SELECTOR
44 2 BR030206 RING, RETAINING
45 1 BR030213 RETAINING RING, 2.00 EXTERNAL
46 2 BR030220 RETAINING RING 1.250 INTERNAL
47 4 BS070201 COM SPRING .56 x .66 1.50 LG
48 2 BS070208 COMPRESSION SPRING
49 CM000211 DECAL, PATENT PENDING
(REMOVED 7/6/09)
50 2 FB030232 BEARING, RADIAL 17 mm
EXTENDED RACE
51 2 FB130206 BEARING, FLANGE 2.00 ID. x 2.25
OD. x 1.00 LG
52 4 FB130212 BUSHING, FLANGE .75 ID x .875
OD x .75 LG
53 2 FC030006 TOLERANCE RING 1.575 ID
54 4 HC620417 BHSCS .250-20 X 1.00
55 1 HC620431 BHSCS .250-20 X 2.00
56 2 HC622820 SHCS .250-20 X 1.25
57 1 HC700415 BHSCS .375-16 X .75
58 8 HC700417 BHSCS .375-16 X 1.00
59 2 HC700426 BHSCS .375-16 X 2.00
60 5 HC700430 BHSCS .375-16 X 2.50
ITEM QTY PART NO. DESCRIPTION
Service
Page 6-4
61 1 HC700432 BHSCS .375-16 X 2.75
62 1 HC702815 SHCS .375-16 X .750
63 2 HF449063 INSERT 3/4 X 1/4-20
64 2 HF700000 PANEL FASTNER, .375-16 , U TYPE
65 8 HN625200 LOCKNUT, .250-20 NYLON
66 9 HN704901 LOCKNUT, .375-16 NYLON
67 1 HN704902 LOCKNUT, .375-16 NYLON
68 1 HP286819 SPIRAL PIN .188 X 1.12
69 2 HS307601 WASHER, FLAT .281 ID X .500 OD X
.062 T
70 5 HS347600 WASHER, SAE .375
71 1 HS347702 WASHER, FLAT .387 ID x 1.753 OD X
.06 THK
72 2 HS720004 WASH, FELT .641 1.250 .125T
73 2 HT512517 TAP SC 10-24 X 1.00 TYPE WB PN HD
PHIL BLK
74 1 HT552515 TAP SC NO. 8-16 X .75 PLASTITE PN
HD PHIL BLK
75 1 HX700428 BHSCS .375-16 X 2.25 SS
76 1 JC620415 BHSCS .250-20 X .75
77 2 JC620422 BHSCS .250-20 x 1.50
78 6 JC700412 BHSCS .375-16 X .50
79 2 JC700420 BHSCS .375-16 X 1.25
80 4 JC700424 BHSCS .375-16 X 1.75
81 1 JN714200 HEX NUT .375-24
82 1 JN714400 NUT, HEX JAM .375-24 UNF
83 8 JS347400 LOCKWASHER, INT TOOTH .375
84 3 PN660200 INSERT, PLASTIC 1.00 DIA-11 GA
85 1 PP090211 INSERT, PL 1.50 SQ X 10-14 GA
86 6 PP130002 INSERT, DOMED PLASTIC
87 6 PP130003 INSERT, DOMED PLASTIC
88 2 PR060003 BUMPER, RECESS
89 2 PR060005 BUMPER, WEIGHT
90 2 PR069400 BUMPER, RECESS
94 1 13061-307 GRIP 3.00”
95 2 4605-514 GRIP 4.5”
96 1 13060-598-X* PLACARD
97 2 4000Y316-X* DECAL,CAUTION
98 1 4605-381-X* DECAL, WARNING
99 3 8500-025-X* DECAL,WARNING
100 1 13060-999-X* OWNERS MANUAL (NOT SHOWN)
101 1 13060-207 CAM, LEG POSTIONING
102 1 01655 SEAT PAD
103 1 4800-176 BACK PAD
104 1 4800-196 THIGH PAD W/WEAR COVER
105 1 4800-199 WEAR COVER
106 1 13000-399 VR1 DECAL
107 1 13000-343 FRONT PANEL
108 1 13000-346 BACK PANEL
109 1 13000-208 LATCH
110 1 13000-100 EDGE TRIM
111 8 HT552511 TAP SCREW 8-16 X .38 BLACK
112 1 13000-101 HALF WEIGHT OPTION 5 LB
113 1 13000-102 HALF WEIGHT OPTION 7.5 LB
114 1 13050-335 DECAL ADJUSTING
115 9 13000-030 WEIGHT PLATE PACK (LIGHT)
116 9 13000-034 WEIGHT PLATE PACK (STANDARD)
117 1 4800-557 DECAL, WEIGHT PLATE 10-150
118 1 13000-552 DECAL, WEIGHT PLATE 10-220
119 1 4700-337 WEIGHT PLATE 10LB
120 1 4700-338 WEIGHT PLATE 15LB
ITEM QTY PART NO. DESCRIPTION
Cybex VR1 Owner’s Manual
*Language Key
1-German
2-French
3-Spanish
4-English
6-Japanese
7-Swedish
8-Russian
