35
8. SPECIFICATIONS
8.1 Technical Specications
HDMI Bandwidth 340MHz/10.2Gbps
Input Ports 3×Cat.5e/6/7 (LAN)
1×3.5mm (Microphone Audio)
1×IR Extender [3.5mm]
Output Ports 1×HDMI
1×VGA
1×TOSLINK (S/PDIF Audio)
1×3.5mm (Stereo Audio)
1×IR Blaster [3.5mm]
1×RS-232 [9-pin D-sub]
4×USB Type-A
Supported Resolutions 480i@60Hz - 4K@30Hz (4:4:4, 8-bit)
VGA@60Hz - WUXGA@60Hz (RB)
IR Frequency 30 - 50kHz (30 - 60kHz under ideal
conditions)
Power Supply 5V/4A DC (US/EU standards, CE/FCC/UL
certied)
ESD Protection Human Body Model:
±12kV (Air Discharge)
±8kV (Contact Discharge)
Dimensions 231.5mm×25mm×108mm (W×H×D)
[Case Only]
231.5mm×25mm×120mm (W×H×D)
[All Inclusive]
Weight 666g
Chassis Material Metal
Silkscreen Color Black
Operating Temperature 0˚C - 40˚C/32˚F - 104˚F
