5
7
CH+/LINK: This button controls multiple functions:
a
Channel +: Press this button momentarily to increase the streaming
channel to the next available channel on the local network.
Note: If no other channels are detected, the channel number will
not change.
b
Video Link: Press and hold the button for 3 seconds to enable or
disable the Video Link. When the link is disabled and the Receiver
is connected to a display it will show the system’s current IP and
rmware information.
c
Reset to Factory Defaults: Press and hold this button when
powering the unit on until both the POWER and LINK lights are
blinking. Once both lights are blinking you can reboot the unit
and all settings will be returned to the factory defaults (Including
resetting the IP mode to auto, broadcast channel to 0, and the
streaming mode to multicast). A new IP address will be assigned
automatically within the 169.254.xxx.xxx address range.
8
CH−/USB: This button controls multiple functions:
a
Channel −: Press this button momentarily to decrease the
streaming channel to the previous available channel on the local
network.
Note: If no other channels are detected, the channel number will
not change.
b
USB: Press and hold the button for 3 seconds to enable/disable
the USB connection between the Transmitter and the Receiver.
(Multicast Mode ONLY)
Note: In Multicast mode is it only possible to provide USB support
to a single Receiver at a time. Enabling USB on one Receiver will
disable it on all other Multicast Receivers on the same channel.
9
IR WINDOW: Accepts IR signals from any standard remote control
and sends the signal to the IR Out on the associated Transmitter.
10
IR IN: Connect to the provided IR Extender to extend the IR control
range of remotely located devices. Ensure that the remote being
used is within direct line-of-sight of the IR Extender.
11
IR OUT: Connect to the provided IR Blaster to transmit IR signals
from the associated Transmitter to devices within direct line-of-sight
of the IR Blaster.
