6.5 RS-232 Commands
Command Description Contents
S SOURCE 1~4 Select input source 1=DVI
2=VIDEO
3=S-VIDEO
4=PC
R SOURCE Inquire input source Reports the numerical equivilent for
SOURCE setting (as above)
S OUTPUT 0~25 Select output timing 0=Native 1=640×480
2=800×600 3=1024×768
4=1280×768 5=1360×768
6=1280×720 7=1280×800
8=1280×1024 9=1440×900
10=1400×1050 11=1680×1050
12=1600×1200 13=1920×1080
16=1920×1200 17=480p
18=720p 60 19=1080p 60
20=1080i 60 22=576p
23=720p 50 24=1080p 50
25=1080i 50(25)
R OUTPUT Inquire output timing Reports the numerical equivilent for
OUTPUT setting (as above)
S SIZE 0~6 Select output size 0=OVERSCAN 1=FULL
2=BEST FIT 3=PAN SCAN
4=LETTER BOX 5=UNDER 2
6=UNDER 1
R SIZE Inquire output size Reports the numerical equivilent for SIZE
setting (as above)
S PCAUTO I PC Mode / Auto Setup
S CONTRAST 0~60 Contrast Setting
R CONTRAST Inquire contrast setting
S BRIGHTNESS 0~60 Brightness setting
R BRIGHTNESS Inquire brightness setting
S HUE 0~60 Hue setting
