CYP CV-401H User Manual

9
6.2 Left Panel
1 2
1
HDMI IN: Connect the HDMI IN port to the HDMI output port of your
source equipment such as a DVD player or Set-top box. You can also
use an HDMI to DVI cable to connect to the DVI output of your PC.
2
DC 5V: Plug the 5 V DC power supply into the unit and connect the
adaptor to AC wall outlet.
6.3 Right Panel
1
2
1
OUTPUT L/R: Connect the L/R stereo output ports to the input ports
of active speakers or TV/monitor with corresponding audio inputs.
2
OUTPUT VIDEO: Connect the VIDEO output port to the composite
video input port of your display such as HDTV or monitor.
