7. CONNECTION DIAGRAM
HDMI OUTUSB
EDID
Wr.
Bypass
Emulator
Rd.
STATUS
SET
1 2
1234
Stored
Select HDMI IN
5678
Default
Blu-ray Player
3D TV/Display
HDMI Input
HDMI Output
