CYP RE-EDID User Manual

12
8. SPECIFICATIONS
Video Bandwidth 300Mbps/9Gbps
Input ports 1×HDMI
1×USB (Power only)
HDMI Input Cable
Distance
10m 1080p@12-bit), 5m (4K×2K)
Output port 1×HDMI
HDMI Output Cable
Distance
10m 1080p@12-bit), 5m (4K×2K)
Resolution Up to 4K×2K@24/25/30Hz
USB Power 5V/500 mA
Dimensions 71mm(W)×65mm(D)×23mm(H)/Exc. Jacks
71mm(W)×71mm(D)×23mm(H)/Inc. Jacks
Weight 108 g
Chassis Material Metal
Colour Black
ESD Protection Human body model:
±8 kV (air-gap discharge)
±4 kV (contact discharge)
Operating Temperature 0 °C ~ 40 °C
Storage Temperature −20 ˚C ~ 60 ˚C / −4 ˚F ~ 140 ˚F
Relative Humidity 20 ~ 90 % RH (non-condensing)
Power Consumption 2.5 W
