Cyrus SmartPower User Instructions
4
GB
GB
TROUBLESHOOTING GUIDE
If your
SmartPower
is not operating properly, disconnect the power and check
all connections using the notes in this manual. If problems persist, the
checklists below may help.
If you are in any doubt, consult your dealer.
No sound from either speaker
Preamplifier mute switch is on Deselect Mute
Loudspeakers are disconnected Check speaker connections
Fault indication on the front panel of
your
SmartPower
See ‘Fault Indication System’
No sound from one loudspeaker
Does your speaker have fuses? Check speaker, replace fuses
Speaker cables or interconnects
faulty
Check connections, cables - replace
if needed
Mono installations: Check connections are correct to
input and output of both amplifiers.
Poor quality sound in two channel stereo mode
Selector switch incorrectly set to
mono
Set the switch to stereo
Poor quality sound in single channel mono mode
Selector switch incorrectly set to
stereo
Set the switch to mono
Speakers plugs not connected to the
correct terminals
Check all speaker connections
carefully
FAULT INDICATION SYSTEM
The
SmartPower
has a powerful protection system and fault indication system
designed to prevent damage to your hi-fi system and help you diagnose a
possible problem. If a fault persists, reset the amplifier via the rear panel
mains switch.
FAULT INDICATIONS
Standby light flashing Green / Yellow
This indicates overload in at least
one channel. If the problem is
temporary (e.g. excessive volume),
normal operation will resume after
ten seconds. If the fault indication
persists, there may be a problem
with the speakers or connections.
Switch off the power at the rear panel
and unplug the speaker cables. If the
fault indication clears when power is
re-applied, check the loudspeakers,
cables and plugs for loose strands of
wire causing a possible short circuit.
Standby light flashing Green
A fault has been reported from the
PSX-R
Switch off the power to the
SmartPower
and the
PSX-R
Switch
on again. If the problem does not
clear, return both units to your
Cyrus
distributor for checking.
The
PSX-R
is disconnected or
switched off.
Check there is power to the
PSX-R
and check the PSX-R connection to
the
SmartPower.
Standby light flashing Yellow / Red
The
SmartPower
has over heated.
Check the ventilation around the
SmartPower.
Allow the unit to cool
down before re-applying power.
MONO light flashing
The STEREO/MONO switch has
been changed whilst the amplifier is
operating.
Return the switch to its original
position.
If after taking remedial measures a fault condition remains, you should return
the
SmartPower
to your
Cyrus
appointed dealer or an authorised Service
Centre.
SPECIFICATIONS
Power Supply
Voltage: ...........................................................................As plate on rear of unit
Power Consumption
Standby ..........................................................................................................6W
ON (No Load) ...............................................................................................23W
ON (2 x 60W/Ch)........................................................................................185W
Safety Requirements...........................................................................EN 60065
Enclosure
Dimensions (WxHxD)............................................................ 215 x 75 x 365mm
Weight ........................................................................................................4.3Kg
Material......................................................................................Die cast chassis
Audio Performance
Input Sensitivity (60W/8
Ω
).............................. RCA ............................... 413mV
Input Impedance ............................................. RCA ..................................20k
Ω
Channel Balance ........................................................................................0.1dB
Frequency Response ..................................... (-3dB)..................... 1Hz-100kHz
Signal to Noise Ratio (A-WTD)........................ (Unwtd)............................102dB
(Ref 60W) (A-wtd) .............................112dB
Signal to Noise Ratio (A-WTD)........................ (Unwtd)..............................85dB
(Ref 1W) (A-wtd) ...............................94dB
Output Power Stereo (Internal PSU) ............... 8 Ohms ...............................60W
Output Power Mono (Internal PSU)................. 8 Ohms .............................105W
Output Power Stereo (with PSX-R)................. 8 Ohms ...............................60W
Output Power Mono (with PSX-R)................... 8 Ohms .............................125W
THD+N (@ 2/3 full power)............................... (20Hz-20kHz)...................0.01%
1kHz...............................0.004%
Cyrus reserves the right to change specifications without notice. E&OE.
WARRANTY
The warranty card enclosed should be completed by the Dealer and the
purchaser and returned to
CYRUS
or its Distributor within 8 days of purchase.
No Dealer or Distributor may vary the terms of this warranty which is personal
to the original Purchaser and is not transferable.
Please retain the sales receipt as proof of purchase.
Warranty claims must wherever possible be made through the Dealer from
whom the equipment was purchased.
This warranty excludes:
•
Damage caused through neglect, accident, misuse, wear and tear, or
through incorrect installation, adjustment or repair by unauthorised
personnel. Any unauthorised servicing will result in loss of guarantee.
•
Liability for damage or loss occurring in transit to or from the purchaser.
•
Consequential damage, loss or injury, arising from or in conjunction with
this equipment.
Equipment for attention under warranty should be consigned return carriage
paid. If returned equipment is found to comply with the published specification,
CYRUS
reserves the right to raise a charge.
The above conditions do not affect your statutory rights as a consumer.
