AXS-convert12 structure is algo adequate to rig
from a truss convert 12A enclosures (2 units
maximum). To this structure will join the first
enclosure of the column with the rods described
before and the safety pins. Make note that the
enclosure will be inverted so that, it will be
recommendable remove previously the weather
protection and turn the front logo. Yo will need two
AXC-AT (not included with AXS-convert12). The
system rigging must be done with the
recommended rigging ironworks and made by
qualified workers. Don´t rig any system from the
handles.
WLL: 84 kgf (184.8 lbf)
Weight: 4.1 Kg (9 lb)
Dimmensions: 10.9 x 56.6 x 31 cm
(Al x An x P) 4.29 x 22.28 x 12.2 in
AXS-convert12
The structure AXS-convert12 is adecuated for
stack, maximum, 3 convert 12A enclosures. To
control the vertical inclination of the column use
the slots from the side pieces, like other
accessories, and with help of the software Ease
Focus. To this structure will join the first enclosure
of the column with the rods described before and
the safety pins.
AXC-AT
2 unidades máx. / 2 units max.
AXS-convert12
convert 12A
avant 118A
(No incluido
Not included)
Note:
You must use for the fixing of the charge lashings with
tensioners with a maximum width of 50mm (2”) for AXS
applications.
Recommended width: 35mm. Lenght: Depends on the place
where convert 12A enclosures are mounted.
20
Manual del Usuario / convert series / User’s Manual
