CONFIGURATIONS
The convert 12A can be employed alone for voice applications where not a high preassure level is
required. For this use, plug the mixer output to the enclosure input. The most frequently use will combine
convert12A and convert18A. In this case, plug the mixer output with input signal of convert18A (subwoofer)
and then, through the SATELLITE OUTPUT connector, send the signal to convert12A.
In case of not place the subwoofers in the same convert12A cluster, it whould be better to send
independent signals to each one of the systems controling the delay in the frequency cut.
subwoofer
Mezclador/Mixer
Retardo/
Delay
Procesador/
processor
convert 12A
8
Manual del Usuario / convert series / User’s Manual
