D-Link DAP-2360 Quick Install Guide

ENGLISH

To power the access point, you can use one of the following methods:

1. Use the supplied power adapter

2. Connect one end of your Ethernet cable into the LAN (PoE) port on the DAP-2360

and the other end into one port on a PoE switch.

To setup and manage the DAP-2360 from a computer, use one of the following methods:

1. Connect a straight through Ethernet cable between the access point and your

computer.

2. Connect the access point to a switch or router and use a computer from a

computer that is also connected to that switch or router.

3. Please start your web browser program, type the

IP address of the device (http://192.168.0.50) and

press Enter. Make sure that the IP addresses of the

device and your computer are in the same subnet.

Then, refer to the Manual for conguration.

Computer

PoE Switch

DAP-2360

Other manuals for D-Link DAP-2360

Questions and Answers:

Need help?

Do you have a question about the D-Link DAP-2360 and is the answer not in the manual?

General

Frequency band	2.4 - 2.4835 GHz
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	150 Mbit/s
Quality of Service (QoS) support	Yes
Networking features	Fast Ethernet
Wireless technology	802.11b/g/n
Compliance industry standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Antenna gain level (max)	5 dBi
Internal	No
Certification	FCC, UL 2043
Interface	Ethernet
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, SSH, SSID, WPA, WPA2
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Power supply type	AC/DC
Power consumption (typical)	9 W
Package depth	272 mm
Package width	204 mm
Package height	114 mm
Package weight	1306 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1843 mm
Pallet gross weight (air)	323840 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	294 mm
Shipping (inner) case height	244 mm
Shipping (inner) case length	600 mm
Shipping (inner) case weight	7270 g
Shipping (inner) case net weight	4500 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)
Harmonized System (HS) code	85176990
