Positioning the Camera
Step 1
Using a Torx Security screwdriver, loosen the
screw on the top of the camera housing.
Step 2
Swivel the camera along it's horizontal
axis until you achieve the desired angle.
Step 3
Using a Torx Security screwdriver, tighten the
screw on the top of the camera housing rmly.
1
2
The DCS-7010L can be adjusted to ensure optimal viewing
when mounted by following the steps outlined.
Step 4
Rotate the camera around its vertical
axis by adjusting the base.
Step 5
Rotate the camera to adjust for
positioning by rotating the barrel.
4
5
