D-Link DES-1024D Quick Intallation Guide

2
Setup The DES-1024D 10/100M Fast
Ethernet Switch
The setup of the Switch can be performed using the following steps:
A. The surface must support at least 5 kg.
B. The power outlet should be within 1.82 meters (6 feet) of the device.
C. Visually inspect the power cord and see that it is secured fully to the AC
power connector.
D. Make sure that there is proper heat dissipation from and adequate
ventilation around the Switch. Do not place heavy objects on the
Switch.
Desktop or Shelf Installation
When installing the Switch on a desktop or shelf, the rubber feet included
with the device must be first attached. Attach these cushioning feet on the
bottom at each corner of the device. Allow enough ventilation space between
the device and the objects around it.
Fast Ethernet Switch installed on a Desktop or Shelf
This Manual: http://www.manuallib.com/file/2426647

D-Link DES-1024D Specifications

General

MAC address table	8000 entries
Store-and-forward	Yes
Maximum data transfer rate	0.1 Gbit/s
Supported data transfer rates	10/100 Mbps
10G support	No
Networking standards	IEEE 802.1Q, IEEE 802.3, IEEE 802.3az, IEEE 802.3i, IEEE 802.3u
Switch type	Unmanaged
Switch layer	L2
Power connector	DC-in jack
Basic switching RJ-45 Ethernet ports quantity	24
Safety	UL
Product color	Black
Storage temperature (T-T)	-10 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 90 %
Dimensions (WxDxH)	280 x 44 x 180 mm
Networking features	Fast Ethernet
Connectivity technology	Wired
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz

Weight and Dimensions

Weight	1900 g
